Biemmedue EC/S 55 Suspended Hot Air Generator
Code: 02EC106 · Suspended Hot Air Generators
Power: 55 kW Automatic diesel burner Socket for connection to a thermostat, humidistat or timer Electric power cable with plug (L = 1.5 m)
- Combustion type
- Indirect (with flue)
- Electrical supply
- single-phase
- Rated power
- 58,6 kW
- Output / efficiency
- 89.5 %
We help you choose the right model for your application.
Description
- Automatic diesel burner
- Socket for connection to a thermostat, humidistat or timer
- Electric power cable with plug (L = 1.5 m)
- Combustion chamber made of AISI 430 stainless steel with four flue gas passes
- Timed post-ventilation system for cooling the combustion chamber
- Electronic flame control
- Overheat thermostat
- Diesel supply hoses made of hydrocarbon-resistant rubber, protected by a metal sheath
- Electric control panel
Technical specifications
| Combustion type | Indirect (with flue) |
|---|---|
| Electrical supply | single-phase |
| Rated power | 58,6 kW |
| Output / efficiency | 89.5 % |
| Air flow | 2.500 m³/h |
| Temperature rise at 20 °C | 66 |
| Consumption | 4,64 kg/h |
| Electrical power input | 850 W |
| Flue diameter | 150 mm |
| Hot air outlet duct diameter | 350 - 300 mm |
| Dimensions | 1.342x470x630 mm |
| Machine weight | 81 kg |
Get a quote
Request a quote for this product
Fill in the form and we will come back with a quote. The more you tell us about the application, the more accurate the quote.
Biemmedue EC/S 55 Suspended Hot Air Generator
Code 02EC106
